Wireless AC Unified Services VPN Yönlendirici
DSR‑1000AC
-
Product Status (Revision A):
Live
Live: The product is actively being manufactured and sold.
D-Link DSR-1000AC Wireless AC Unified Services VPN Yönlendirici, küçük ve orta ölçekli işletmelerin artan ihtiyaçlarını karşılamak için güvenli, yüksek performanslı ağ çözümleri sunar. Yeni nesil kablosuz ağ performansıyla 1300 Mbps'ye kadar kablosuz hızlar sağlar.
Specs
|
Tip |
VPN security router |
|---|---|
|
Kablosuz ağ standardı |
Wireless AC |
|
Frekans bandı |
Simultane çift-band |
|
Kablosuz ağ hızı |
1300 Mbps 5 GHz 300 Mbps 2.4 GHz |
|
Anten tipi |
3 adet sökülebilir çok yönlü anten |
|
Anten kazancı |
2 dBi - 2.4 GHz 2 dBi - 5 GHz |
|
Kablo portu |
2 x Gigabit Ethernet WAN 4 x Gigabit Ethernet LAN |
|
USB portu |
2 x USB 2.0 |
|
Konsol portu |
+ |
|
İç ortam/dış ortam |
İç ortam |
|
Kasa tipi |
Metal |
|
Wireless modları |
Access Point (AP) |
|
Gelişmiş özellikler |
MIMO |
|
Maximum number of SSIDs |
4 |
|
WEP 64/128 bit |
+ |
|
WPA/WPA2-Personal/Enterprise |
+ |
|
TKIP/AES şifreleme |
+ |
|
Firewall throughput |
950 Mbps |
|
VPN throughput (3DES) |
250 Mbps |
|
Concurrent sessions |
100000 |
|
Firewall policies |
600 |
|
Internet connection type |
Multiple PPPoE PPPoE/L2TP/PPTP Static/Dynamic IP |
|
Firewall system |
Dynamic DNS Dynamic route Inter-VLAN route Intrusion prevention system (IPS) NAT, PAT Static route Web content filtering |
|
Networking |
3G redundancy DHCP relay DHCP server/client IEEE802.1q VLAN IP multicast IPv6 Outbound load balancing Route failover VLAN (port-based) |
|
VPN tunnels |
155 |
|
IPSec tunnels |
70 |
|
SSL VPN tunnels |
20 |
|
Encryption methods |
DES, 3DES, AES, Twofish, Blowfish, CAST-128, NULL RC4-128, 3DES, AES |
|
VPN features |
Dead Peer Detection Hub and Spoke IP Authentication Header (AH) IP Encapsulating Security Payload (ESP) IPSec NAT Traversal IPSec/PPTP/L2TP Server VPN Tunnel Keep Alive |
|
Bandwidth management |
Port-based QoS |
|
WEB |
+ |
|
SNMP (v1, v2c, v3) |
+ |
|
CLI |
+ |
Support
| Version | Date | Type | File Size | |
|---|---|---|---|---|
| Datasheet EN | - | 0.69mb | Download |
