Wireless AC1750 Wave 2 Dual-Band PoE Erişim Noktası
DAP‑2680
-
Product Status (Revision A):
Live
Live: The product is actively being manufactured and sold.
- 802.11ac Wave 2 wireless, 1.75 Gbps1 hıza kadar
- MU-MIMO with beamforming
- Band steering
- Gigabit PoE-capable LAN port
- AP Array utility support
- Ücretsiz D-Link Central WiFiManager
Specs
|
Tip |
Software Managed AP |
|---|---|
|
Kablosuz ağ standardı |
Wireless AC Wave 2 |
|
Frekans bandı |
Simultane çift-band |
|
Kablosuz ağ hızı |
1300 Mbps 5 GHz 450 Mbps 2.4 GHz |
|
Anten tipi |
Tümleşik çok yönlü antenler |
|
Anten kazancı |
3.6 dBi - 2.4 GHz 4_2 dBI for 5 GHz |
|
Power-over-Ethernet |
+ |
|
Kablo portu |
1 x Gigabit Ethernet LAN |
|
İç ortam/dış ortam |
İç ortam |
|
Kasa tipi |
Plastik |
|
Wireless modları |
Access Point (AP) WDS bridge WDS with AP Wireless client |
|
Gelişmiş özellikler |
MU-MIMO SmartBeam |
|
Maximum number of SSIDs |
8 per radio |
|
Otomatik kanal seçimi |
+ |
|
WMM-PS/802.11e (U-APSD) |
+ |
|
Wi-Fi scheduler |
+ |
|
AP traffic load balance |
+ |
|
L2 roaming |
+ |
|
WEP 64/128 bit |
+ |
|
WPA/WPA2-Personal/Enterprise |
+ |
|
TKIP/AES şifreleme |
+ |
|
WPA_WPA2_PSK over WDS |
+ |
|
WLAN partition |
+ |
|
SSID broadcast disable |
+ |
|
Station isolation |
+ |
|
MAC adresi filtreleme |
+ |
|
802.1X authentication |
+ |
|
Yönetim platformu |
Central WiFiManager (CWM-100) |
|
WEB |
+ |
|
SNMP (v1, v2c, v3) |
+ |
|
Telnet |
+ |
|
SSH |
+ |
Support
| Version | Date | Type | File Size | |
|---|---|---|---|---|
| Datasheet EN | - | 0.46mb | Download |
| Version | Description | Date | Type | File Size | |
|---|---|---|---|---|---|
| - | Product Manual | - | 7.78mb | Download |
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:
http://tsd.dlink.com.tw/GPL.asp
The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
http://tsd.dlink.com.tw/GPL.asp
The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
| Version | Description | Date | |
|---|---|---|---|
| - | Manual | - | Download |
| Version | Description | Date | |
|---|---|---|---|
| - | Additional downloads | - | Download |
