Wireless N PoE Dış Mekan Erişim Noktası
DAP‑3315
-
Product Status (Revision A):
Live
Live: The product is actively being manufactured and sold.
- 12 dBi yönlü sektör anteni
- Neme dayanıklı kasa
- Birden çok çalışma modu
- 8 SSID'ye kadar destek
Specs
|
Tip |
Software Managed AP |
|---|---|
|
Kablosuz ağ standardı |
Wireless N |
|
Frekans bandı |
Single-band |
|
Kablosuz ağ hızı |
300 Mbps 2.4 GHz |
|
Anten tipi |
Embedded sector antenna |
|
Anten kazancı |
12 dBi - 2.4 GHz |
|
Power-over-Ethernet |
+ |
|
Kablo portu |
2 x Fast Ethernet LAN |
|
İç ortam/dış ortam |
Dış ortam |
|
Kasa tipi |
Plastik |
|
IP rating |
IPX5 |
|
Wireless modları |
Access Point (AP) WDS bridge WDS with AP Wireless client Wireless extender |
|
Maximum number of SSIDs |
8 |
|
Otomatik kanal seçimi |
+ |
|
WMM-PS/802.11e (U-APSD) |
+ |
|
Wi-Fi scheduler |
+ |
|
AP traffic load balance |
+ |
|
L2 roaming |
+ |
|
WPA/WPA2-Personal/Enterprise |
+ |
|
TKIP/AES şifreleme |
+ |
|
WPA_WPA2_PSK over WDS |
+ |
|
WLAN partition |
+ |
|
SSID broadcast disable |
+ |
|
Station isolation |
+ |
|
MAC adresi filtreleme |
+ |
|
802.1X authentication |
+ |
|
DHCP server |
+ |
|
802.1D STP |
+ |
|
IGMP snooping |
+ |
|
ARP spoofing |
+ |
|
SNTP |
+ |
|
WEB |
+ |
|
Syslog |
+ |
